SPEEDROLLERS FOR INDOOR USE

Novoferm SpeedRollers for indoor use

SpeedRollers for indoor use are designed to be mounted inside a building.

This can be in a passageway between rooms or on the inside of an exterior wall.

Which door is most suitable for your situation depends on many factors.

Firstly, the size and wind pressure in the passageway.

Often, smaller spaces will have less wind pressure than between large halls or in an airlock.

SpeedRoller Prime

THE QUICK, SILENT SOLUTION TO DRAUGHT

The SpeedRoller Prime is a good solution for medium-sized openings up to 12.25 m2 and normal use. Ideal for the daily passage of people and light goods. The one-piece door curtain is extremely quiet and can be printed with any required imprint. Novoferm SpeedRollers are used in many supermarkets because they are practical in use, save a lot of energy and improve the atmosphere in the shopping area with their beautiful, clear print.

Advantages at a glance

PROPERTIES

PRIME

Max. surface area (W x H)

12.25 m2

Max. width (W)

3,500 mm

Max. height (H)

3,500 mm

Minimum wind load [* with WindLoad Optimiser]

3 / 7* Bft

Max. wind load class - EN 12424

0

Opening speed with frequency control

1.5 m/s

Closing speed with frequency control

0.5 m/s

Opening / closing speed with standard control

1 m/s

Door curtain thickness (standard / optional)

0.7 / 1.2 mm

Fabric weight (standard / optional)

680 / 1400 gr/m2

Suitable as an outside door

No



* Depending on configuration





12.25 m2
Max. surface area
3,500 × 3,500 mm (B × H)

3 [7] Bft
Max. Wind load class in Bft
[with WindLoad Optimiser]

1.5 m/s
Max. opening speed
with frequency control

APPLICATION
• SUPERMARKETS
• FOOD INDUSTRY
• LABORATORIES
• LIGHT INDUSTRY
FEATURES

Extra safe: the soft FlexEdge bottom bar (option)




  • Wind resistant
    up to at least 3 Bft or even up to 7 Bft with WindLoad Optimiser. Class 0 according to EN12424
  • Silent
    the door curtain is manufactured in one piece and is therefore virtually noise-free
  • Safe
    equipped with a safety light curtain as standard, optionally with a soft FlexEdge bottom beam
  • Robust
    steel guide columns guide the door curtain made of polyester-reinforced plastic fabric
  • Draught-Free
    the door curtain is sealed with sliding strips, the bottom beam has a rubber sealing profile
  • Chique
    the door leaf can be provided with a fullcolour print of your own design! How about a nice photo of your products, or your logo or your logo, or a photo that fits nicely into your interior?

SpeedRoller Prime-XF

THE EXTRA FAST, SILENT SOLUTION AGAINST DRAUGHTS

The fast SpeedRoller Prime-XF is designed for high speed in intensive use. Ideal for fast passage of people and light goods. This innovative door is very widely applicable for openings up to 12.25 m2. The one-piece door curtain is extremely quiet and can be printed with any required imprint. Especially the high speed makes this door very suitable for passages that are used very frequently. With a cord switch or motion detector, your staff can pass through in no time.

Advantages at a glance

PROPERTIES

PRIME-XF

Max. surface area (W x H)

12.25 m2

Max. width (W)

3,500 mm

Max. height (H)

3,500 mm

Minimum wind load [* with WindLoad Optimiser]

3 / 7* Bft

Max. wind load class - EN 12424

0

Opening speed with frequency control

2.3 m/s

Closing speed with frequency control

0.5 m/s

Opening / closing speed with standard control

1 m/s

Door curtain thickness (standard / optional)

1.2 mm

Fabric weight (standard / optional)

1400 gr/m2

Suitable as an outside door

No



* Depending on configuration





12.25 m2
Max. surface area
W x H = 3,500 x 3,500 mm

3 [7] Bft
Max. Wind load class in Bft
[with WindLoad Optimiser]

2.3 m/s
Max. opening speed
with frequency control

APPLICATION
• SUPERMARKETS
• FOOD INDUSTRY
• LABORATORIES
• LIGHT INDUSTRY
Features

The aluminium top roller is light and fast




  • WIND RESISTANT
    up to at least 3 Bft or even up to 7 Bft with WindLoad Optimiser. Class 0 according to EN12424
  • WALKING
    or driving through the door in a hurry is a breeze with the PRIME-XF. With a motion detector or remote control - for example - the door opens so fast that traffic hardly has to slow down
  • SILENT
    the door curtain is manufactured in one piece and is therefore virtually noise-free
  • SAFE
    equipped with a safety light curtain as standard, optionally with a soft FlexEdge bottom beam
  • ROBUST
    steel guide columns guide the door curtain made of polyester-reinforced plastic fabric
  • DRAUGHT-FREE
    the door curtain is sealed with sliding strips, the bottom beam has a rubber sealing profile

SpeedRoller Strong-E

ALL ESSENTIAL FUNCTIONS IN AN ECONOMY PACKAGE

The SpeedRoller Strong-E is a good solution for openings up to 9 m2 with moderate wind pressure. Ideal for the daily passage of people and light goods. The reinforcement profiles provide additional stability. The opening speed of 1.8 m/s makes this door practical even in heavy traffic. Useful for production processes that run quickly and where downtimes are not tolerated.

This innovative door has a very wide range of use.

Advantages at a glance

PROPERTIES

STRONG-E

Max. surface area (W x H)

9 m2

Max. width (W)

3,000 mm

Max. height (H)

3,500 mm

Minimum wind load [* with WindLoad Optimiser]

8 Bft

Max. wind load class - EN 12424

0

Opening speed with frequency control

1.8 m/s

Closing speed with frequency control

0.5 m/s

Opening / closing speed with standard control

1 m/s

Door curtain thickness (standard / optional)

0.7 mm

Fabric weight (standard / optional)

680 gr/m2

Suitable as an outside door

No



* Depending on configuration





9 m2
Max. surface area
W x H = 3,000 x 3,500 mm

0 [min. 8 Bft]
Max. Wind load class
in accordance with EN 12424

1.8 m/s
Max. opening speed
with frequency control

APPLICATION
• DISTRIBUTIE CENTRA
• WAREHOUSES
• VOEDINGSMIDDELEN INDUSTRIE
• LICHTE TOT ZWARE INDUSTRIE
FEATURES

Reinforcement profiles for stability and speed




  • WIND RESISTANT
    up to at least 8 Bft. Class 0 according to EN12424
  • FAST
    the Strong-E is ideal for fast walking or driving through, even in situations with slightly higher wind pressure, such as production halls.
    If your production process needs to run quickly, the Strong-E gives you the continuity you need.
  • SAFE
    equipped with a safety light curtain as standard, optionally with a soft FlexEdge bottom beam
  • ROBUST
    steel guide columns guide the door curtain made of plastic fabric with reinforcement profiles
  • DRAUGHT-FREE
    the door curtain is sealed with sliding strips, the bottom beam has a rubber sealing profile

SpeedRoller Strong

APPEARANCE AND PERFORMANCE IN PERFECT HARMONY

The SpeedRoller STRONG is designed for high speed and intensive use. Ideal for the fast passage of people and goods, also in situations with high wind pressure.

Applicable for openings up to 25 m2. The reinforcing profiles provide additional stability. The opening speed of 1.8 m/s makes this door practical even for heavy traffic and large passages. Ideal for large production processes that run quickly and where breakdowns are not allowed to occur.

Wind load*
Up to 3,000 mm width Class 2
Up to 4,000 mm width Class 1
Up to 5,000 mm width Class 0 (7 Bft)

Advantages at a glance

PROPERTIES

STRONG

Max. surface area (W x H)

25 m2

Max. width (W)

5,000 mm

Max. height (H)

5,000 mm

Minimum wind load [* with WindLoad Optimiser]

7 Bft

Max. wind load class - EN 12424

2 *

Opening speed with frequency control

1.8 m/s

Closing speed with frequency control

0.5 m/s

Opening / closing speed with standard control

1 m/s

Door curtain thickness (standard / optional)

0.7 / 1.2 mm

Fabric weight (standard / optional)

680 / 1400 gr/m2

Suitable as an outside door

No



* Depending on configuration





25 m2
Max. surface area
W x H = 5,000 x 5,000 mm

2* [min. 7 Bft]
Max. Wind load class
in accordance with EN 12424

1.8 m/s
Max. opening speed
with frequency control

APPLICATION
• DISTRIBUTION CENTRES
• WAREHOUSES
• LARGE INDUSTRIAL HALLS
• HEAVY INDUSTRY
FEATURES

WindLoad Optimiser1:
maximum wind resistance




  • WIND RESISTANT
    up to at least 7 Bft. (5,000 x 5,000 mm) Class 2 according to EN12424 (up to 3,000 mm wide)
  • FAST
    opening and closing fast, and doing so very often, is the strength of the SpeedRoller STRONG.
  • MAXIMUM
    reliability under all conditions with this SpeedRoller for indoor use
  • NOISE REDUCTION
    the door leaf is provided with additional sound insulation as standard
  • DRAUGHT-FREE
    the door curtain is sealed with sliding strips, the bottom beam has a rubber sealing profile
  • SAFE
    equipped with a safety light curtain as standard, optionally with a soft FlexEdge bottom beam
  • ROBUST
    with the WindLoadOptimiser the Strong becomes even sturdier and more stable in high wind loads



1 Optional
*Depending on configuration

SpeedRoller Strong-FV (Fullversion)

A CLEAR SOLUTION FOR BUSY PASSAGES

The SpeedRoller Strong-FullVision is the transparent version of the standard rapid roll door for indoors:

reliable technology for years of trouble-free operation and a good view. Ideal for passages that are frequently used from several directions. It is immediately obvious when someone is coming from the other side of the door, so accidents caused by poor visibility are prevented.

Wind load*
Up to 3,000 mm width Class 2
Up to 4,000 mm width Class 1
Up to 5,000 mm width Class 0 (7 Bft)

Advantages at a glance

PROPERTIES

STRONG-FV

Max. surface area (W x H)

25 m2

Max. width (W)

5,000 mm

Max. height (H)

5,000 mm

Minimum wind load in Beaufort

7 Bft

Max. wind load class - EN 12424

2 *

Opening speed with frequency control

1.8 m/s

Closing speed with frequency control

0.5 m/s

Opening / closing speed with standard control

1 m/s

Door curtain thickness

0.8 mm

Suitable as an outside door

Yes



* Depending on configuration





25 m2
Max. surface area
W x H = 5,000 x 5,000 mm

2* [min. 7 Bft]
Max. Wind load class
in accordance with EN 12424

1.8 m/s
Max. opening speed
with frequency control

APPLICATION
• LIGHT TO HEAVY INDUSTRY
• WORKSHOPS WITH HEAVY TRAFFIC FROM BOTH DIRECTIONS
• SITUATIONS WHERE HIGH VISIBILITY IS REQUIRED
• DRIVE-THROUGH AREAS
FEATURES

A clear view of what is happening in the other room




  • WIND RESISTANT
    up to at least 7 Bft. (5,000 x 5,000 mm) Class 2 according to EN12424 (up to 3,000 mm wide)
  • COMPLETELY TRANSPARENT
    the traffic on the other side of the door is clearly visible
  • NOISE REDUCTION
    the door leaf is fitted with additional sound insulation as standard and is almost noise-free
  • SAFE
    equipped with a safety light curtain as standard
  • ROBUST
    steel guide columns guide the door curtain made of highly flexible transparent plastic
  • DRAUGHT-FREE
    the door curtain is sealed with sliding strips, the bottom beam has a rubber sealing profile
  • INSTALLATION
    in any passageway up to 25 m2 inside the building, not suitable for installation in the outer wall

SpeedRoller NovoZip

SELF-REPAIRING RAPID ROLL DOOR

The self-repairing SpeedRoller NovoZip is the ideal solution for openings of up to 20.25 m2 and intensive use.

The self-repairing operation of the self-lubricating track reduces interruptions and ensures minimum delay in the production process.

The NovoZip is intended as a fast, user-friendly room divider and provides very good draught exclusion and climate control.

This results in significant energy savings.

Advantages at a glance

PROPERTIES

NOVOZIP

Max. surface area (W x H)

20.25 m2

Max. width (W)

4,500 mm

Max. height (H)

4,500 mm

Minimum wind load in Beaufort

11 Bft

Max. wind load class - EN 12424

3 *

Opening speed with frequency control

2.0 m/s

Closing speed with frequency control

0.5 m/s

Door curtain thickness

1.0 mm

Fabric weight Class M2

900 gr/m2

Fabric weight (option)

1050 gr/m2

Suitable as an outside door

Yes



* Depending on configuration





20.25 m2
Max. surface area
W x H = 4,500 x 4,500 mm

3 [min. 11 Bft]
Max. Wind load class
in accordance with EN 12424

2.0 m/s
Max. opening speed
with frequency control

APPLICATION
• SUPERMARKETS
• FOOD INDUSTRY
• LABORATORIES
• INDUSTRY
EIGENSCHAFTEN

The SelfRepair function guarantees continuity



  • WIND RESISTANT
    up to at least 11 Bft. Class 3 according to EN12424
  • SELF-REPAIRING
    the door curtain automatically returns into the columns after a collision
  • SILENT
    the door curtain is manufactured in one piece and is therefore virtually noise-free
  • AFE
    equipped with a safety light curtain and a soft FlexEdge bottom beam as standard
  • ROBUST
    steel guide columns guide the door curtain made of polyester-reinforced plastic fabric
  • DRAUGHT PROOF
    the zip fastener technology ensures a good draught proofing, as does the rubber sealing.
  • INSTALLATION
    in every passageway up to 20.25 m2 in the building and on the inside of the external facade

Made to measure and controllers!
