MAGNUM
The Magnum door is the ideal solution when an intermediate size is needed: it is perfect for rooms that cannot accommodate the Elite+ series, but where the Novoslide sliding door cannot be installed. Its structure is composed of vertical modular panels, usually assembled directly on site.
It shares many features with the Elite+ range: customisable dimensions, RAL painting in any colour, the possibility of stainless steel construction, and compatibility with various accessories, while maintaining maximum freedom of customisation, a feature common to all our products, so as to adapt to any design requirement.
Magnum, however, has certain specificities that set it apart:
- Fire resistance EI 60 / 120, to guarantee high protection.
- Only available in a hinged version, with no sliding alternatives.
- Fixing exclusively on dowels, for direct and stable anchorage.
- 5-wing hinges, designed for greater tightness.
- Three-sided frame, suitable for light installation.
- Smoke control class SA, available for EI 60 version.
Robust, reliable and high-performance, Magnum strikes an excellent balance between security, dimensional flexibility and solid construction.
It is also available in the Metal version, without fire resistance.
TECHNICAL CHARACTERISTICS:
- Fire resistance class EI 60/120 minutes
- Constructed of coplanar steel modules insulated internally with high-density insulation pack
- Three-sided frame, nominal cross-sectional area 146 x 120 mm, suitable for flush or rebated installation
- Heat-expanding perimeter seal
- Sliding on multi-sector bearing hinges, adjustable
- Standard: door closer, 5-wing hinges, fire lock, pair of black handles with plate, cylinder with three keys
- Closing system by means of hydraulic overhead pump and/or counterweights for large dimensions
- Surfaces protected with galvanisation and embossed surface finish with epoxy-polyester powder
- Closing selector in case of two-leaf door
- Maximum feasible dimensions: 3600 x 3600 mm
CUSTOMISATIONS AND ACCESSORIES
COLOURS
STANDARD COLOURS
COLOURS WITH SURCHARGE
Discontinued RAL not available: RAL 1003, 1014, 1021, 2011, 6011, 6018, 6027, 6028, 6033
Do you need anything else?
The door can be produced in any RAL colour of your choice for an additional charge.
Our dealers are available to guide you in selecting the most suitable shade.
